Pump Cavitation


One of the more serious causes of pump failure is cavitation, CPM see the symptoms of cavitation on a regular basis and through their regular technical updates hope to ensure that engineers are more aware of the symptoms. We are sure that everyone has seen the resultant damage from Cavitation and CPM often advise on the effects of cavitation and how best to address this and prevent inefficiency when examining the failures to pumps.

So, what is Pump Cavitation?

The best explanation we heard of Pump cavitation was the formation and subsequent collapse or implosion of vapour bubbles (REF.1) in a pump. This occurs when the absolute pressure on the liquid falls below the liquid’s vapour pressure. When the vapour bubbles collapse with high enough frequency, it sounds like marbles and rocks are moving through the pump. If the vapour bubbles collapse with high enough energy, they can remove metal from the internal casing wall, and leave indent marks appearing like blows from a large ball pein hammer.

Pump 1

Ref. 1 – Formation and implosion of bubbles

Getting more technical it is the inadequate NPSH (net positive suction head) available (NPSHa) which is a root cause for cavitation in the pump. Insufficient NPSH leads to lower liquid pressure in the pump and if pressure in the eye of the impeller falls below the vapour pressure of the fluid, then cavitation can begin by formation of vapour bubbles.

What are the symptoms and effects of cavitation on the pump?

The main symptoms of cavitations are noise and vibration. This can be monitored by regular scheduling and analysis of the noise and vibration conditions using such non-invasive methods such as vibration analysis and ultrasound technologies. CPM’s advice is to make this part of your regular PPM’s as often as you feel necessary. CPM use these technologies as part of their Asset Management Programmes or on an ‘Ad hoc’ basis as part of a fault finding investigation. The results are very accurate.

If the pump is allowed to continue to operate under these adverse cavitating conditions for too long, the following damage can occur:

  • Pitting marks on the impeller blades and on the internal volute casing wall of the pump (Ref.2)
  • Premature bearing failure
  • Premature mechanical seal failure
  • Shaft breakage and other fatigue failures in the pump


Pump 2 Pump 4Pump 3

Ref. 2 – Severe wear caused by cavitation

Other problems caused but not limited to pump cavitation are:

  • Problems with pump packing.
  • Problems with mechanical seals.
  • Problems with alignment.
  • Problems with the bearings.
  • Problems with impellers, casings, and wear bands.
  • Problems with pump efficiency.


These problems will only exacerbate the inevitable failure of your pumps until you resolve cavitation at its source.

Types of pump cavitation

  • Vaporization cavitation, also called inadequate NPSHa cavitation.
  • Internal re-circulation cavitation.
  • Vane passing syndrome cavitation.
  • Air aspiration cavitation.
  • Turbulence cavitation.


CPM’s comprehensive asset management programmes, have been developed with the aim of reducing your costs by preventing failures. They use advanced Condition Based Monitoring techniques, predictive and preventative maintenance technologies as in their ‘Repair, Replace, Manage Maintain’ culture, but in a comprehensive ‘joined up’ programme. Computerised diagnostics and asset management expertise stop failures.

The objectives of these programmes are to divert the costs away from repairs to proactive maintenance activities. CPM’s ‘Manage’ services are the next step from their ‘Maintain’ services; it not only analyses what needs doing accurately but also what corrective action is required to avoid a reoccurrence.
